FS 2204 ELITE FPV Drone motor
As low as:
$16.50
As low as:
only left for same day shipping. Order now!
FS 2204 ELITE FPV Drone motor
The FS series of MAD FPV brushless motors is specifically designed for freestyle flying. The development process involved six months of rigorous testing, resulting in refined aesthetics and improved functionality.The main difference between the FS and BSC series is the lightweight titanium shaft and the 0.15mm silicon steel sheet, which increases efficiency. Additionally, the product has an aesthetically pleasing appearance due to secondary anodizing.
About this product
Motor Data |
|||||||||
| Motor Model |
MAD Dynamo FS2004 V1.0 |
Motor Number of slots |
12N14P | ||||||
| Motor Size |
D:24.3 × 17.25 mm |
Rotor Balance |
≤5 mg | ||||||
| Propeller Mounting Holes |
D:5 M2X2 D:6 M2X2 |
Motor Balance |
D:12 M2×4 |
||||||
| Shaft Diameter |
IN: 1.5 mm | Cable Length |
130 mm 24# Awg(Black) silicone |
||||||
